Marantz SR5014 (UK version)

Marantz SR5014 was introduced in 2019. It is equipped with 7 channel amplifier and is capable of 7.1 maximum channel processing.

We evaluated the Receiver and gave 60 overall score out of 100. Our ranking system is based on the amplifier specifications, audio and video features, connectivity, multizone capabilities, radio and many other details.

Amplifier score is based on power ratings, minimum impedance load, power supply, transformer type, total harmonic distortion, damping factor, signal to noise ratio and other small details. Audio score depends on the number of channels, front wide channel support, maximum channel processing, support of audio formats, DAC specifications, room calibration algorithm... Video score is based on HDR, Dolby Vision and video signal passthrough and upscaling, analog to HDMI upconversion. Connectivity score is defined from all wired and wireless inputs and outputs, internet and bluetooth connections, HEOS, SONOS and others. Multizone score depends on the number of zones with their outputs. Radio score is evaluated form digital radio support and analog tuner with its frequency range, signal to noise ratio, harmonic distortion...

In this section we present pros and cons of Marantz SR5014.

Here we are comparing Marantz SR5014 to its predecessor SR5013 and displaying the major changes.

UPGRADES	Marantz SR5014	Marantz SR5013
Dolby Atmos Height Virtualization	✔	✖
Domotz Pro Compatible	✔	✖
Remote Monitoring with ihiji	✔	✖
OvrC Compatible	✔	✖
Enhanced Audio Return Channel (eARC)	✔	✖
Newer HDCP Version	2.3	2.2
Newer Bluetooth Version	4.1	3.0 + EDR

DOWNGRADES	Marantz SR5014	Marantz SR5013
Multi-Channel Input	✖	✔ 7.1

For more detailed comparison between the models please visit Marantz SR5014 vs Marantz SR5013.

Amplifier

Marantz SR5014 has 7 channel amplifier and delivers 100 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven) and also has a stable performance at 4 Ω load.

Video Features

The Receiver has 4K passthrough up to 60p and 4K upscaling up to 30p. It can bypass HDR10, Dolby Vision.

HDR10

High-dynamic-range (HDR) video has greater dynamic range than standard-dynamic-range (SDR) video with brigter whites and deeper blacks. HDR10 was announced on August 27, 2015, by the Consumer Technology Association and uses the wide-gamut Rec. 2020 color space. It sends static metadata via video stream to the TV which calibrates its screen brightness and color according to that. HDR10 supports up to 1000 nits of brightness and 10-bit color which corresponds to 1024 shades of the primary RGB colors.

Dolby Vision

Dolby Vision is an update to HDR10 by adding dynamic metadata that can be used to more accurately adjust brightness levels up to 10,000 nits maximum brightness on a scene-by-scene or frame-by-frame basis and supports up to 12-bit color depth (4096 shades of RGB) and 8K resolution.

Dolby Atmos and Dolby Surround upmixer

Marantz SR5014 supports Dolby Atmos with its Dolby Surround upmixer. It can be configured upto 5.1.2 channels using internal amplifiers.

Dolby Atmos is the first cinematic audio format in which sounds exist as individual entities, called audio objects. In Dolby Atmos, any sound - the helicopter, a car screeching around a corner, a melodic bird call - can exist as an independent audio object, free of channel restrictions. They can be precisely placed and moved anywhere in your room, including overhead, to flow above and around you in three-dimensional space. Through the use of audio objects, overhead sound, and all the richness, clarity, and power of Dolby sound, Dolby Atmos turns your room into an amazing place for entertainment. You'll feel like you're inside the action, in ways you've never experienced before.

Dolby Atmos for the home represents every sound in the original cinema mix as an audio object. Extensions to the Dolby Audio™ codecs, along with an advanced scalable algorithm, allow Dolby Atmos to be delivered via Blu-ray Disc and streaming media. A spatially-coded substream is added to Dolby TrueHD or Dolby Digital Plus. A Dolby Atmos audio/video receiver (AVR) adapts the cinema experience to your home theater from seven speakers to as many as 34 in 24.1.10 configuration, recreating the original artistic concept. The format supports up to 128 simultaneous independent audio objects in a mix for rich, realistic, and breathtaking sound. It recreates the director's original concept through descriptive metadata to provide customized playback for home theater and delivers sounds above you through overhead speakers, special upward-firing Dolby Atmos speakers, or a Dolby Atmos enabled sound bar.

If the content is not mixed in Dolby Atmos then the Dolby surround upmixer will expand the audio to all channels including ceiling speakers. The upmixer has replaced the Dolby Pro Logic II family with improved upmixing algorithms.

DTS:X and Neural:X upmixer

Marantz SR5014 supports DTS:X with its Neural:X upmixer. It can be configured upto 5.1.2 channels using internal amplifiers.

A technique used in DTS:X is similar to the one used in Dolby Atmos. Instead of a fixed number of channels, DTS:X defines object locations from the listener in polar coordinates. An a/v receiver then dynamically renders sound according to the current speaker configuration. The speaker layout employed by DTS:X is the sum of Dolby Atmos and Auro-3D. It has standard 7.1 channel base layer, a 5 channel height layer above the base layer on the front and side walls, and 3 rows of speakers on the ceiling.

DTS Neural:X is a new upmixer that can take non DTS:X content and upmix it to the DTS:X speaker layout. It has replaced the DTS Neo family with improved flexibility.

Current Feedback Topology

Marantz SR5014 features Current Feedback Topology which is a well known, Marantz’ original circuit technology. The Current Feedback amplifier technology fits perfectly with the high requirements set for Super Audio software providing wide-bandwidth, high-speed reproduction. The impedance at the Current Feedback point is limited resulting in a very low phase shift. Marantz receivers and amplifiers equipped with Current Feedback can keep the phase compensation via Negative FeedBack (NFB) to a minimum, resulting in high through-rate, excellent transient response and superb sonic transparency for the full bandwidth. Unlike conventional Voltage Feedback amplification, the Current Feedback amplification makes the power amplifier in-sensitive to difficult loudspeaker loads.

HDAM

Marantz SR5014 features exclusive Marantz HDAM (Hyper Dynamic Amplifier Module) technology found on their Reference Series components. Marantz developed its own discrete circuit boards to replace standard IC's. These HDAM's consist of discrete surface mount components with short mirror image L/R signal paths. Those devices are doing exactly the same thing as the Op-Amps, but outperform the regular IC Op-amps dramatically in terms of the Slew Rate and reduced noise level, resulting in a much more dynamic, accurate and detailed sound. Over the years Marantz developed different types of the HDAM to improve quality and to fit to the special requirements of a product category like CD or amplifier.

MDAX2

Compressed music enhancement in Marantz SR5014 is done by Marantz’ MDAX2 technology. The use of compressed audio files like MP3, Windows Media™ Audio or AAC is getting more and more popular. The audio quality of these compressed files however is less than the original lossless files that are on a CD, especially lacking the higher frequencies and affecting the lower frequencies which make the audio image less wide and deep. The Marantz Digital Audio Expander 2, also called M-DAX2, recalculates the outputted frequency range. This enables you to get a more detailed and clearer sound.

Audyssey

Marantz SR5014 comes with Audyssey Dynamic EQ and Audyssey Dynamic Volume.

Audyssey Dynamic EQ selects the best possible frequency response and surround volume levels moment-by-moment. This ensures that the bass response, tonal balance and surround impression remain constant despite changes in volume. This is the first technology that carefully combines information from incoming source levels with actual output sound levels in the room, a pre-requisite for delivering a dynamic volume solution.

Your Listening experience can be greatly diminished when there are significant shifts in volume between television programs, commercials and within the program material itself. When this happens you must constantly adjust the volume to maintain your desired listening level. Audyssey Dynamic Volume monitors the volume of program material moment-by-moment and automatically adjusts it, maintaining the desired listening level for all content while optimizing the dynamic range to preserve impact.

Room Correction

Marantz SR5014 comes with Audyssey MultEQ XT room correction system and includes the calibration microphone. It also supports Audyssey App.

Audyssey is an acoustic measurement technology which automatically restores the acoustic distortion caused by the acoustic behaviour of a room with only a push on a button. Audyssey equalization provides an clear, accurate, natural sound with voices and dialog that become focused and intelligible, restoring the musical balance. Musical instruments and sound effects become precisely localized and the surround soundstage is made seamless and enveloping.

Connectivity

Marantz SR5014 can be connected to internet using ethernet cable or built-in wi-fi adapter. It can also connect to bluetooth devices via built-in bluetooth adapter. The Receiver works with Amazon Alexa and supports AirPlay 2. It has 8 HDMI inputs and HDCP 2.3 copy protection. There is a phono input with built-in phono stage for connecting the cartridge output of the turntable directly to the Receiver. There are 7.2 channel analog pre-outs for external amplification.

Front panel has HDMI and USB inputs.

Here we list all the available features and specifications of Marantz SR5014.

BASICS
Brand	Marantz
Model	SR5014
Type	A/V Receiver
Country	UK
Release Year	2019

AMPLIFIER
Channels	7.2
Front Wide Channel Support	✖
Current Feedback Topology	✔
Discrete Amplification	✔
HDAM	✔
THX™ Certification	✖
Continuous 6 Ω Rated	✔
Certified 4 Ω Performance	✔
Bi-amp Capability	✔ assignable

AUDIO
DAC	AKM AK4458
Maximum Channel Processing	7.1
Air Studios Monitor Certification	✖
Dolby Atmos	✔ up to 5.1.2
Dolby Atmos Height Virtualization	✔
Dolby TrueHD	✔
Dolby Digital Plus	✔
Dolby Surround Upmixer	✔
Dolby Pro Logic	✖
Dolby Digital EX	✔
Surround EX	✖
DTS:X	✔ up to 5.1.2
DTS Neural:X	✔
DTS Virtual:X	✔
DTS Neo	✖
DTS-HD Master Audio	✔
DTS-HD High Resolution Audio	✔
DTS 96/24	✔
DTS Express	✔
DTS-ES	✔ Discrete 6.1, Matrix 6.1
IMAX Enhanced	✖
Auro 3D with Auro-Matic Upmixer	✖
PCM	✔ 2-ch/Multi-ch Input
Music Playback via USB	MP3, WMA, AAC, Apple Lossless, WAV, FLAC, DSD
High Resolution Music Playback via USB and/or Network	✔ up to 192 kHz
High Resolution Audio Formats via USB	Apple Lossless, WAV, FLAC, DSD
Multi-Channel Music File Playback via USB	✖
Gapless Playback	✔
DSD via HDMI	✖
DSD via USB	✔ 2-ch Input
DSD to PCM Converter	✖
USB DAC	✖
Jitter Reduction	✖
DTS Dialogue Control	✔
Dialog Enhancement	✖
Dialog Level Adjustment	✔
Dialog Normalization	✔
Dialogue Lift	✖
Compressed Music Enhancer	✔ MDAX2
High-resolution Music Enhancer	✖
Audyssey Dynamic EQ	✔
Audyssey Dynamic Volume	✔
Audyssey LFC	✖
Audyssey Sub EQ HT	✖
Audyssey DSX	✖
Direct Mode	✔
Pure Direct Mode	✔
Independent Dual Subwoofer Output	✖

CALIBRATION
Auto Speaker Calibration System with Mic.	✔ Audyssey MultEQ XT
Audyssey App Support	✔
Optimized Bass Redirection	✔
Bass Sync	✖

VIDEO
HDR10	✔
HDR10+	✖
Dynamic HDR	✖
BT.2020 color space	✔
Dolby Vision	✔
Hybrid Log Gamma (HLG)	✔
Quick Media Switching (QMS)	✖
Auto Low Latency Mode (ALLM)	✖
Variable Refresh Rate (VRR)	✖
Quick Frame Transport (QFT)	✖
3-D Ready	✔
Video Signal Passthrough	up to 4K 50/60Hz 4:4:4
Video Signal Upscaling	✔ up to 4K 24/25/30p 4:4:4
Analog To HDMI Upconversion	✔ Component**, Composite
Component Video Upscaling	✖
Analog to Analog Video conversion	✖
isf Certified Calibration Control	✔

CONNECTIVITY
MHL Input	✖
DLNA 1.5	✔
FireConnect	✖
FlareConnect	✖
Domotz Pro Compatible	✔
Remote Monitoring with ihiji	✔
OvrC Compatible	✔
HEOS	✔
Chromecast Built-In	✖
DTS Play-Fi	✖
Works with Amazon Alexa	✔
Google assistant	✔
Apple Siri	✔
Works with SONOS	✖
AirPlay	✔ AirPlay 2
Apple Product Connection	✔ iPod, iPhone and iPad
Remote App	✔ Marantz 2016 AVR Remote App for iOS and Android devices
InstaPrevue Input Source Prevue	✖
Ethernet	✔
Ethernet Switch	✖
Wi-Fi	✔
Bluetooth	✔ SBC
HDBaseT Compatible	✖
Enhanced Audio Return Channel (eARC)	✔
HDCP Version	2.3
HDMI Inputs	8 (1 front)
HDMI Outputs	2 (simultaneous)
USB Input	1 (Front) for USB memory
USB DC Out Port	✖
Analog Audio Line Inputs	4
Analog Audio Line Outputs	✖
Phono Input	✔
Optical Inputs	2
Optical Outputs	✖
Coaxial Inputs/Outputs	2 / No
Composite Video Inputs	2
Composite Video Outputs	1
S-Video Inputs	✖
S-Video Outputs	✖
Component Video Inputs	2
Component Video Outputs	1
PC In	✖
Multi-Channel Input	✖
Analog Pre-Outs	7.2
XLR Inputs	✖
XLR Pre-outs	✖
Front A/V Inputs	HDMI, USB
Speaker A/B	✔ assignable
Headphone Out	✔ 6.3 mm

ZONES
Zones	2
Powered Zones	✔ 2
Zone 2 Outs	Pre Out
RS-232 Interface	✔
+12V Trigger Output	1

MISC
On-Screen Display	✔ Advanced Graphic User Interface
GUI Languages	9
Web Control	✔
IP Control	✔
FL Display	✔ port hole
Remote Controller	RC035SR
Pre-programmed / Learnable / LCD Display	No / No / No
Detachable Power Cord	✔
Flasher In	✔
Remote Control In/Out	1 / 1
Setup Assistant	✔

RADIO
Analog Tuner	✔ FM/AM with RDS
Digital Radio	✖
Internet Radio	✔ TuneIn
Pandora	✖
Spotify	✔
Tidal	✔
Deezer	✔
Napster	✔
SiriusXM Internet Radio	✖

CONSTRUCTION
Front Panel	Metal
Speaker Terminals	7
Large Speaker Terminals	7
Color-Coded Speaker Terminals	✔
Transparent High-Grade Speaker Terminals	✖
High Grade Audio Components	✔
Gold plated RCA terminals	✖

POWER
Power Supply	AC 230 V, 50/60 Hz
Toroidal Transformer	No (EI)
Power Consumption	650 W
No Sound Power	ECO On/Off: 45 W/75 W
Standby Power	0.2 W

GENERAL
ECO Mode / Hybrid Standby Function	✔
Auto Power off	✔
Dimensions (W x H x D)	440 mm x 161 mm x 348 mm (with antenna: 440 mm x 231 mm x 348 mm) 17-3/8" x 6-3/8" x 13-3/4" (with antenna: 17-3/8" x 9-1/8" x 13-3/4")
Dimensions of Package (W x H x D)	519 mm x 242 mm x 428 mm
Weight	10.1 kg (22.2 lbs)
Weight of Package	12.3 kg
Warranty	3 Years

SPECS
Power Output (8 Ω, 20 Hz - 20 kHz, 2 channel driven, FTC)	100 W (0.08% THD)
Power Output (6 Ω, 1 kHz, 2 channel driven, FTC)	140 W (0.7% THD)
Maximum Effective Power Output (6 Ω, 1 kHz, 1 channel driven, JEITA or IEC)	200 W (10% THD)
Rated Power Output (6 Ω, 1 kHz, 1 channel driven, IEC)	180 W (1% THD)
Phono Distortion	0.03% (1 kHz, 3 V)
Input Sensitivity and Impedance (Line)	200 mV/47 kΩ
Input Sensitivity and Impedance (Phono MM)	2.5 mV
S/N Ratio (Line, IHF-A)	100 dB
S/N Ratio (Phono MM, IHF-A)	74 dB
Phono RIAA Deviation	±1 dB (20 Hz to 20 kHz)
Frequency Response (Analog In)	+1/-3 dB (10 Hz to 100 kHz, Direct mode)
DSD Sampling Rates via USB	5.6 MHz, 2.8 MHz
Video Input Sensitivity/Output Level and Impedance	1 Vp-p/75 Ω (Component Y) 0.7 Vp-p/75 Ω (Component PB/CB, PR/CR) 1 Vp-p/75 Ω (Composite)
Video Frequency Response	5 Hz - 60 MHz, 0, -3 dB (Component) 5 Hz - 10 MHz, 0, -3 dB (Composite)
Ethernet Standard	100BASE-TX
Wi-Fi Standard	IEEE 802.11 a/b/g/n
Wi-Fi Terminal Frequency	5 GHz, 2.4 GHz
Bluetooth Version	4.1
Bluetooth Frequency	2.4 GHz
USB Terminal	USB2.0 5V, 1 A
FM Frequency	87.5 MHz - 108.0 MHz
FM 50 dB Quiet Sensitivity (IHF, 1 kHz, 100% MOD.)	Mono: 2.8 µV (20.2 dBf)
FM Effective Sensitivity	1.2 µV (12.8 dBf)
FM S/N Ratio	Mono/Stereo: 70 dB/67 dB
FM Harmonic Distortion (IHF, 1 kHz)	Mono/Stereo: 0.7%/1.0%
AM Frequency	522 kHz - 1611 kHz
AM Effective Sensitivity	18 µV

* - 480i/576i and 480p/576p only
** - 480i/576i only
*** - no 1080p/24 upconversion
**** - 1080p signal is not converted

In 2020 Marantz SR5014 was replaced by SR5015. Let us now have a look at some important changes that the successor brought.

UPGRADES	Marantz SR5015	Marantz SR5014
HDR10+	✔	✖
Dynamic HDR	✔	✖
QMS	✔	✖
Auto Low Latency Mode Pass-through	✔	✖
VRR	✔	✖
QFT	✔	✖
Video Signal Passthrough	up to 8K 50/60Hz and 4K 100/120Hz 4:4:4	up to 4K 50/60Hz 4:4:4
Video Signal Upscaling	✔ up to 8K 50/60Hz and 4K 100/120Hz 4:4:4	✔ up to 4K 24/25/30p 4:4:4
Newer Bluetooth Version	4.2	4.1

DOWNGRADES	Marantz SR5015	Marantz SR5014
Less HDMI Inputs	6 (one 8K input)	8 (1 front)

For more detailed comparison between the models please visit Marantz SR5015 vs Marantz SR5014.
