Canon EOS Rebel XT vs Nikon D5500

In this comparison, we will evaluate the Canon EOS Rebel XT and the Nikon D5500, highlighting the advantages of each over the other, discussing their pros and cons, shared strengths and weaknesses, and providing a rating based on their available features and specifications to assist you in choosing the one that best suits your needs.

Canon EOS Rebel XT was introduced in April 2005 and Nikon D5500 was introduced in January 2015. Let us first list highlights of the models.

Now that we've looked at the most essential specifications and gained a basic understanding of these cameras, we can delve into more details and see the differences between them.

This section shows those features and specifications which are the reason to choose Nikon D5500 over Canon EOS Rebel XT.

We already listed pros and cons of each model. However, you may also find useful to look at their common strengths and weaknesses shown side-by-side.

Screen

Canon EOS Rebel XT has a 1.8" Fixed screen with 115k dot resolution and Nikon D5500 has a 3.2" Fully Articulated screen with 1,037k dot resolution. Fully articulated screen makes Nikon D5500 selfie and vlogger friendly and generally very useful for video shooting. Nikon D5500 also features touchscreen which has advantages such as easy menu navigation, intuitive controls, quick setting adjustment and most importantly a Touch-to-Focus functionality (available only on Nikon D5500) allowing users to select a specific point on the screen where they want the camera to focus. This feature can be helpful for achieving precise focus in both photo and video recording.

Viewfinder

Cameras have built-in Optical (pentamirror) viewfinders. They both have 95% coverage.

Canon EOS Rebel XT features a 8 megapixel APS-C CMOS sensor with dimensions of 22.2 x 14.8 mm and a total area of 328.6 mm². Its native ISO range is 100 - 1,600. Nikon D5500 features a 24.2 megapixel APS-C CMOS sensor with dimensions of 23.5 x 15.6 mm and a total area of 243.4 mm². Its native ISO range is 100 - 25,600.

Here is a sensor size comparison chart where you can see how different sensors compare with each other:

Sensor size chart

	Sensor	Dimensions	Area	Aspect Ratio	Crop Factor
	Medium Format	44 x 33 mm	1452 mm2	4:3	0.79x
	Full Frame	36 x 24 mm	864 mm2	3:2	1x
	APS-H	27 x 18 mm	486 mm2	3:2	1.3x
	APS-C	23.6 x 15.6 mm	368.2 mm2	3:2	1.5x
	APS-C (Canon)	22.3 x 14.9 mm	332.3 mm2	3:2	1.6x
	Micro Four Thirds	17.4 x 13 mm	226.2 mm2	4:3	2x
	1-inch	13.2 x 8.8 mm	116.2 mm2	3:2	2.7x
	1/1.7-inch	7.44 x 5.58 mm	41.5 mm2	4:3	4.7x
	1/2.3-inch	6.17 x 4.55 mm	28.1 mm2	4:3	5.6x

Canon EOS Rebel XT can take pictures up to 3456 x 2304 resolution. It can also take pictures with lower resolution like 2496 x 1664, 1728 x 1152 with 3:2 aspect ratios. Nikon D5500 is equipped with EXPEED 4 processor and can take pictures up to 6000 x 4000 resolution. It can also take pictures with lower resolution like 4496 x 3000, 2992 x 2000 with 3:2 aspect ratios.

Lens Mount

Canon EOS Rebel XT has Canon EF/EF-S lens mount and Nikon D5500 has Nikon F lens mount. They both have APS-C sensor but because of a small size difference their crop factors (also called lens multiplier) differ from each other. Canon EOS Rebel XT has the crop factor of 1.6x which means that a 35mm equivalent focal length of the mounted lens will be equal to its actual focal length times 1.6. Nikon D5500 has the crop factor of 1.5x which means that a 35mm equivalent focal length of the mounted lens will be equal to its actual focal length times 1.5.

No Low-Pass Filter on Nikon D5500

There is no optical low-pass filter (OLPF), also known as an anti-aliasing filter, in front of the sensor on Nikon D5500. This results in a slightly sharper image but may also introduce moiré patterns and aliasing artifacts when photographing subjects with fine, repetitive patterns or details.

No Image Stabilization

The cameras do not have image stabilization. On Canon EOS Rebel XT it means that you need lenses with optical image stabilization for vibration reduction. As for Nikon D5500 nothing can be done. On Nikon D5500 it means that you need lenses with optical image stabilization for vibration reduction. As for Canon EOS Rebel XT nothing can be done.

Built-in Wi-Fi on Nikon D5500

Nikon D5500 has a built-in Wi-Fi which allows to easily transfer photos and videos from the camera to other Wi-Fi-enabled devices, such as smartphones, tablets, printers, or computers. This eliminates the need for cables and allows for quick and convenient media sharing and social media integration. It gives you the ability to control your camera remotely using a smartphone or tablet. This is particularly useful for taking self-portraits, group shots, or capturing images in challenging conditions without having to touch the camera. Firmware updates can also be downloaded and installed wirelessly.
  Check out the cameras in our database that have built-in WiFi.

USB Inputs and HDMI Outputs

Both models have USB 2.0 (480 Mbit/sec) inputs for data transfer. connector for video signal output.

Battery

Nikon D5500 comes with EN-EL14,EN-EL14a battery pack with battery life of 820 shots.

External Storage Slots

Canon EOS Rebel XT has a single CompactFlash (Type I/II) card slot. Nikon D5500 has a single SD/SDHC/SDXC card slot.

Shutter

Canon EOS Rebel XT has Electronically Controlled Vertical-travel Mechanical Focal-plane shutter. Nikon D5500 has Electronically controlled vertical-travel focal-plane shutter. Shutter speed can go up to 1/4000 sec on Canon EOS Rebel XT, and up to 1/4000 sec on Nikon D5500. Canon EOS Rebel XT can shoot continuously up to 2.8 fps. Nikon D5500 can shoot continuously up to 5.0 fps.

Focusing

Canon EOS Rebel XT has Dual Pixel CMOS AF system with 7 focusing points and Nikon D5500 has 39 (9 cross-type) focusing points. Nikon D5500 has detection range from -1 to +19 EV.

Exposure

Exposure meterings of Canon EOS Rebel XT and Nikon D5500 range from +1 to +20 EV and 0 to +20 EV respectively and you can set the exposure compensation within the ±2 EV range on Canon EOS Rebel XT and ±5 EV range on Nikon D5500. You can also do exposure lock, exposure bracketing and manual exposure adjustment on Canon EOS Rebel XT and exposure lock, exposure bracketing and manual exposure adjustment on Nikon D5500.

Flash

Cameras have built-in flash with maximum range of 12.00 m at ISO 100.. They also accept external flash which can be connected via Hot Shoe to Nikon D5500. The fastest flash synchronization speed is 1/200 sec on both cameras.

Canon EOS Rebel XT body has dimensions of 127 x 94 x 64 mm (5 x 3.7 x 2.52") and Nikon D5500 body has dimensions of 124 x 97 x 70 mm (4.88 x 3.82 x 2.76"). Canon EOS Rebel XT weighs 540 g (1.19 lb / 19.05 oz) and Nikon D5500 weighs 420 g (0.93 lb / 14.82 oz).

Canon EOS Rebel XT

Nikon D5500

127 mm

94 mm

124 mm

97 mm

94 mm

97 mm

64 mm

70 mm
