Canon EOS 7D Mark II vs Pentax K10D

In this comparison, we will evaluate the Canon EOS 7D Mark II and the Pentax K10D, highlighting the advantages of each over the other, discussing their pros and cons, shared strengths and weaknesses, and providing a rating based on their available features and specifications to assist you in choosing the one that best suits your needs.

Canon EOS 7D Mark II was introduced in September 2014 and Pentax K10D was introduced in December 2006. Let us first list highlights of the models.

Now that we've looked at the most essential specifications and gained a basic understanding of these cameras, we can delve into more details and see the differences between them.

This section shows those features and specifications which are the reason to choose Canon EOS 7D Mark II over Pentax K10D.

This section shows those features and specifications which are the reason to choose Pentax K10D over Canon EOS 7D Mark II.

We already listed pros and cons of each model. However, you may also find useful to look at their common strengths and weaknesses shown side-by-side.

Screen

Canon EOS 7D Mark II has a 3.0" screen with 1,040k dot resolution and Pentax K10D has a 2.5" screen with 210k dot resolution. Both have Fixed screens.

Viewfinder

Cameras have built-in Optical (pentaprism) viewfinders. Canon EOS 7D Mark II has 100% coverage with 1x (0.63x 35mm equivalent) magnification and Pentax K10D has 95% coverage with 0.95x (0.63x 35mm equivalent) magnification.

Canon EOS 7D Mark II features a 20.2 megapixel APS-C CMOS sensor with dimensions of 22.4 x 15 mm and a total area of 336 mm². Its native ISO range is 100 - 16,000 and expands to 100 - 51,200 in boosted mode. Pentax K10D features a 10.2 megapixel APS-C CCD sensor with dimensions of 23.5 x 15.7 mm and a total area of 246.5 mm². Its native ISO range is 100 - 1,600.

Here is a sensor size comparison chart where you can see how different sensors compare with each other:

Sensor size chart

	Sensor	Dimensions	Area	Aspect Ratio	Crop Factor
	Medium Format	44 x 33 mm	1452 mm2	4:3	0.79x
	Full Frame	36 x 24 mm	864 mm2	3:2	1x
	APS-H	27 x 18 mm	486 mm2	3:2	1.3x
	APS-C	23.6 x 15.6 mm	368.2 mm2	3:2	1.5x
	APS-C (Canon)	22.3 x 14.9 mm	332.3 mm2	3:2	1.6x
	Micro Four Thirds	17.4 x 13 mm	226.2 mm2	4:3	2x
	1-inch	13.2 x 8.8 mm	116.2 mm2	3:2	2.7x
	1/1.7-inch	7.44 x 5.58 mm	41.5 mm2	4:3	4.7x
	1/2.3-inch	6.17 x 4.55 mm	28.1 mm2	4:3	5.6x

Canon EOS 7D Mark II is equipped with Dual DIGIC 6 processor and can take pictures up to 5472 x 3648 resolution. It can also take pictures with lower resolution like 4104 x 2736 (M-Raw), 3648 x 2432, 2736 x 1824, 1920 x 1080, 720 x 480 with 3:2, 16:9 aspect ratios. Pentax K10D can take pictures up to 3872 x 2592 resolution. It can also take pictures with lower resolution like 3008 x 2000, 1824 x 1216 with 3:2 aspect ratios.

Lens Mount

Canon EOS 7D Mark II has Canon EF/EF-S lens mount and Pentax K10D has Pentax K_AF2 lens mount. They both have APS-C sensor but because of a small size difference their crop factors (also called lens multiplier) differ from each other. Canon EOS 7D Mark II has the crop factor of 1.6x which means that a 35mm equivalent focal length of the mounted lens will be equal to its actual focal length times 1.6. Pentax K10D has the crop factor of 1.5x which means that a 35mm equivalent focal length of the mounted lens will be equal to its actual focal length times 1.5.

In-Body Image Stabilization on Pentax K10D

Pentax K10D has a built-in Sensor Shift in-body image stabilization (IBIS). This means that you are still getting vibration reduction when camera is paired with non-image stabilizied lenses. It also works with lenses with optical image stabilization and in combination can achieve even better compensation.

Built-in GPS on Canon EOS 7D Mark II

Canon EOS 7D Mark II has a built-in GPS (Global Positioning System) technology which allows you to automatically tag the location where you took your photos. You can later categorize, organize, and search for photos based on location. This is very useful for travel and outdoor photographers for documenting the locations where images were captured.
  Check out the cameras in our database that have built-in GPS.

USB Inputs and HDMI Outputs

Both models have USB inputs for data transfer. connector for video signal output.

Battery

Canon EOS 7D Mark II comes with LP-E6N battery pack with battery life of 670 shots.

External Storage Slots

Canon EOS 7D Mark II has two card slots - one for SD/SDHC/SDXC (UHS-I) and one for CompactFlash (UDMA 7). Pentax K10D has a single SD/SDHC card slot.

Shutter

Canon EOS 7D Mark II has Electronically Controlled Vertical-travel Mechanical Focal-plane shutter. Pentax K10D has Electronically controlled Vertical Run Focal Plane shutter. Shutter speed can go up to 1/8000 sec on Canon EOS 7D Mark II, and up to 1/4000 sec on Pentax K10D. Canon EOS 7D Mark II can shoot continuously up to 10.0 fps. Pentax K10D can shoot continuously up to 3.0 fps.

Focusing

Canon EOS 7D Mark II has Dual Pixel CMOS AF system with 65 (65 cross-type) focusing points and Pentax K10D has 11 focusing points. Canon EOS 7D Mark II has detection range from -3 to +18 EV.

Exposure

Exposure meterings of Canon EOS 7D Mark II ranges from 0 to +20 EV and you can set the exposure compensation within the ±5 EV range on Canon EOS 7D Mark II and ±3 EV range on Pentax K10D. You can also do exposure lock, exposure bracketing and manual exposure adjustment on Canon EOS 7D Mark II and exposure lock, exposure bracketing and manual exposure adjustment on Pentax K10D.

Flash

Cameras have built-in flash with maximum range of 12.00 m on Canon EOS 7D Mark II. They also accept external flash which can be connected via Hot Shoe or PC Terminal to Canon EOS 7D Mark II and via Hot Shoe to Pentax K10D. The fastest flash synchronization speed is 1/250 sec on Canon EOS 7D Mark II and 1/180 sec on Pentax K10D.

Canon EOS 7D Mark II body has dimensions of 149 x 112 x 78 mm (5.87 x 4.41 x 3.07") and Pentax K10D body has dimensions of 142 x 101 x 70 mm (5.59 x 3.98 x 2.76"). Canon EOS 7D Mark II weighs 910 g (2.01 lb / 32.10 oz) and Pentax K10D weighs 793 g (1.75 lb / 27.97 oz).

Canon EOS 7D Mark II

Pentax K10D

149 mm

112 mm

142 mm

101 mm

112 mm

101 mm

78 mm

70 mm
