Canon EOS 7D Mark II vs Canon EOS 7D

In this comparison, we will evaluate the Canon EOS 7D Mark II and the Canon EOS 7D, highlighting the advantages of each over the other, discussing their pros and cons, shared strengths and weaknesses, and providing a rating based on their available features and specifications to assist you in choosing the one that best suits your needs.

Canon EOS 7D Mark II was introduced in September 2014 and Canon EOS 7D was introduced in November 2009. Let us first list highlights of the models.

Now that we've looked at the most essential specifications and gained a basic understanding of these cameras, we can delve into more details and see the differences between them.

This section shows those features and specifications which are the reason to choose Canon EOS 7D Mark II over Canon EOS 7D.

This section shows those features and specifications which are the reason to choose Canon EOS 7D over Canon EOS 7D Mark II.

We already listed pros and cons of each model. However, you may also find useful to look at their common strengths and weaknesses shown side-by-side.

Screen

Canon EOS 7D Mark II and Canon EOS 7D have 3.0" Fixed screens with 1,040k dot and 920k dot resolutions respectively.

Viewfinder

Cameras have built-in Optical (pentaprism) viewfinders. They both have 100% coverage and 1x (0.63x 35mm equivalent) magnification.

Canon EOS 7D Mark II features a 20.2 megapixel APS-C CMOS sensor with dimensions of 22.4 x 15 mm and a total area of 336 mm². Its native ISO range is 100 - 16,000 and expands to 100 - 51,200 in boosted mode. Canon EOS 7D features a 18.0 megapixel APS-C CMOS sensor with dimensions of 22.3 x 14.9 mm and a total area of 222 mm². Its native ISO range is 100 - 6,400 and expands to 100 - 12,800 in boosted mode.

Here is a sensor size comparison chart where you can see how different sensors compare with each other:

Sensor size chart

	Sensor	Dimensions	Area	Aspect Ratio	Crop Factor
	Medium Format	44 x 33 mm	1452 mm2	4:3	0.79x
	Full Frame	36 x 24 mm	864 mm2	3:2	1x
	APS-H	27 x 18 mm	486 mm2	3:2	1.3x
	APS-C	23.6 x 15.6 mm	368.2 mm2	3:2	1.5x
	APS-C (Canon)	22.3 x 14.9 mm	332.3 mm2	3:2	1.6x
	Micro Four Thirds	17.4 x 13 mm	226.2 mm2	4:3	2x
	1-inch	13.2 x 8.8 mm	116.2 mm2	3:2	2.7x
	1/1.7-inch	7.44 x 5.58 mm	41.5 mm2	4:3	4.7x
	1/2.3-inch	6.17 x 4.55 mm	28.1 mm2	4:3	5.6x

Canon EOS 7D Mark II is equipped with Dual DIGIC 6 processor and can take pictures up to 5472 x 3648 resolution. It can also take pictures with lower resolution like 4104 x 2736 (M-Raw), 3648 x 2432, 2736 x 1824, 1920 x 1080, 720 x 480 with 3:2, 16:9 aspect ratios. Canon EOS 7D is equipped with Dual DIGIC 4 processor and can take pictures up to 5184 x 3456 resolution. It can also take pictures with lower resolution like 5184 x 3456, 3888 x 2592, 3456 x 2304, 2592 x 1728 with 3:2 aspect ratios.

Lens Mount

Cameras have Canon EF/EF-S lens mount. Due to their APS-C sensor their crop factor (also called lens multiplier) is equal to 1.6x. This means that a 35mm equivalent focal length of the mounted lens will be equal to its actual focal length times 1.6.

No Image Stabilization

The cameras do not have image stabilization. On Canon EOS 7D Mark II it means that you need lenses with optical image stabilization for vibration reduction. As for Canon EOS 7D nothing can be done. On Canon EOS 7D it means that you need lenses with optical image stabilization for vibration reduction. As for Canon EOS 7D Mark II nothing can be done.

Built-in GPS on Canon EOS 7D Mark II

Canon EOS 7D Mark II has a built-in GPS (Global Positioning System) technology which allows you to automatically tag the location where you took your photos. You can later categorize, organize, and search for photos based on location. This is very useful for travel and outdoor photographers for documenting the locations where images were captured.
  Check out the cameras in our database that have built-in GPS.

USB Inputs and HDMI Outputs

Both models have USB inputs for data transfer. Canon EOS 7D Mark II has a Mini HDMI and Canon EOS 7D has a Mini HDMI connector for video signal output.

Battery

Canon EOS 7D Mark II comes with LP-E6N battery pack with battery life of 670 shots and Canon EOS 7D comes with LP-E6 battery pack with battery life of 800 shots.

External Storage Slots

Canon EOS 7D Mark II has two card slots - one for SD/SDHC/SDXC (UHS-I) and one for CompactFlash (UDMA 7). Canon EOS 7D has a single CompactFlash (Type I/II, UDMA 7) card slot.

Shutter

Canon EOS 7D Mark II has Electronically Controlled Vertical-travel Mechanical Focal-plane shutter. Canon EOS 7D has Electronic shutter and Mechanical Focal Plane shutter. Shutter speed can go up to 1/8000 sec on Canon EOS 7D Mark II, and up to 1/8000 sec on Canon EOS 7D. Canon EOS 7D Mark II can shoot continuously up to 10.0 fps. Canon EOS 7D can shoot continuously up to 8.0 fps.

Focusing

Canon EOS 7D Mark II has Dual Pixel CMOS AF system with 65 (65 cross-type) focusing points and Canon EOS 7D has 19 focusing points. Canon EOS 7D Mark II has detection range from -3 to +18 EV.

Exposure

Exposure meterings of Canon EOS 7D Mark II and Canon EOS 7D range from 0 to +20 EV and +1 to +20 EV respectively and you can set the exposure compensation within the ±5 EV range. You can also do exposure lock, exposure bracketing and manual exposure adjustment on Canon EOS 7D Mark II and exposure bracketing and manual exposure adjustment on Canon EOS 7D.

Flash

Cameras have built-in flash with maximum range of 12.00 m.. They also accept external flash which can be connected via Hot Shoe or PC Terminal to Canon EOS 7D Mark II and via Hot Shoe or PC Terminal or Wireless Speedlite EX to Canon EOS 7D. The fastest flash synchronization speed is 1/250 sec on both cameras.

Canon EOS 7D Mark II body has dimensions of 149 x 112 x 78 mm (5.87 x 4.41 x 3.07") and Canon EOS 7D body has dimensions of 148 x 111 x 74 mm (5.83 x 4.37 x 2.91"). Canon EOS 7D Mark II weighs 910 g (2.01 lb / 32.10 oz) and Canon EOS 7D weighs 860 g (1.90 lb / 30.34 oz).

Canon EOS 7D Mark II

Canon EOS 7D

149 mm

112 mm

148 mm

111 mm

112 mm

111 mm

78 mm

74 mm
