Yamaha RX-A3070 vs Marantz SR7012

Here we are comparing Yamaha RX-A3070 to Marantz SR7012 to reveal their common strengths and weaknesses as well as the differences between them which will help you in making a correct decision before the purchase. Both receivers have 9 channel amplifiers with Yamaha RX-A3070's being more powerful.

Yamaha RX-A3070	Marantz SR7012
Yamaha RX-A3070 was introduced in 2017 and represented a flagship model of a manufacturer. It is equipped with 9 channel amplifier with 150 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven) power per channel and is capable of 11.2 maximum channel processing. It supports Dolby Atmos and DTS:X, passes 4K/60Hz and upscales up to 4K 60p 4:4:4 video signal.	Marantz SR7012 was introduced in 2017. It is equipped with 9 channel amplifier with 125 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven) power per channel and is capable of 11.2 maximum channel processing. It supports Dolby Atmos, DTS:X and Auro-3D, passes 4K/60Hz and upscales up to 4K 50/60Hz 4:4:4 video signal.

We evaluated Yamaha RX-A3070 and Marantz SR7012 and gave them scores of 93 and 92 out of 100 recpectively. Our ranking system is based on the amplifier specifications, audio and video features, connectivity, multizone capabilities, radio and many other details.

For more details about the ranking please go to    Evaluations section.

This section shows those features and specifications which are the reason to choose Yamaha RX-A3070 over Marantz SR7012.

	Yamaha RX-A3070	vs	Marantz SR7012
Higher Power Output	150 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven)	vs	125 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven)
DTS Neo	Neo:6	vs
Network Audio Formats	MP3, WMA, MPEG-4 AAC, Apple Lossless, WAV, FLAC, AIFF, DSD	vs	MP3, WMA, MPEG-4 AAC, Apple Lossless, WAV, FLAC, DSD
Music Playback via USB	MP3, WMA, AAC, Apple Lossless, WAV, FLAC, AIFF, DSD	vs	MP3, WMA, AAC, Apple Lossless, WAV, FLAC, DSD
High Resolution Audio Formats via USB	Apple Lossless, WAV, FLAC, AIFF, DSD	vs	Apple Lossless, WAV, FLAC, DSD
Dialogue Lift	no presence speakers required	vs
High-resolution Music Enhancer	up to 96/24	vs
Newer HDCP Version	2.3	vs	2.2
More Optical Inputs	3	vs	2
More Coaxial Inputs/Outputs	3	vs	2
More RCA Line Inputs	8 (1 front)	vs	6 (1 front)
XLR Line Inputs	1	vs
More Zones	4	vs	3
Web Control		vs
Pandora		vs
SiriusXM		vs
Higher Power Output (8 Ω, 20 Hz - 20 kHz, 2 channel driven, FTC)	150 W (0.06% THD)	vs	125 W (0.05% THD)
Higher S/N Ratio (Line, IHF-A)	110 dB	vs	100 dB
Higher S/N Ratio (Phono MM, IHF-A)	95 dB	vs	74 dB
Wider AM Frequency Range	530 kHz - 1710 kHz	vs	522 kHz - 1611 kHz

This section shows those features and specifications which are the reason to choose Marantz SR7012 over Yamaha RX-A3070.

	Yamaha RX-A3070	vs	Marantz SR7012
Dolby Digital EX		vs
DTS Virtual:X		vs
Auro 3D with Auro-Matic Upmixer		vs	Built-In
Audyssey Dynamic EQ		vs
Audyssey Dynamic Volume		vs
Audyssey LFC		vs
Audyssey Sub EQ HT		vs
isf Certified Calibration Control		vs
AirPlay	AirPlay	vs	AirPlay 2
More HDMI Outputs	2 (1 for MAIN, 1 for Sub/Zone2/ZONE4)	vs	3 (2 for MAIN, 1 for ZONE2)
Multi-Channel Input		vs	7.1
More Composite Video Outputs		vs	1
More Component Video Inputs	2	vs	3
More Component Video Outputs		vs	1
Front A/V Inputs	HDMI, USB, Analog Audio	vs	HDMI, USB, Composite, L/R Audio
Speaker A/B		vs	assignable
Zone 2 Outs	HDMI, RCA Preout	vs	HDMI, Component, Composite, Pre Out
Analog Tuner	FM/AM	vs	FM/AM with RDS
Color-Coded Speaker Terminals		vs
Gold plated RCA terminals		vs
Bigger Power Supply	490 W	vs	710 W
Higher Power Output (6 Ω, 1 kHz, 1 channel driven, JEITA)	230 W (10% THD)	vs	235 W (10% THD)
Wi-Fi Standard	IEEE 802.11 b/g/n	vs	IEEE 802.11 a/b/g/n
Wi-Fi Terminal Frequency	2.4 GHz	vs	5 GHz, 2.4 GHz
Newer Bluetooth Version	2․1 + EDR	vs	3․0 + EDR

We already listed pros and cons of each model. However, you may also find useful to look at their common strengths and weaknesses shown side-by-side.

STRENGTHS	Yamaha RX-A3070	Marantz SR7012
High Power Output	150 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven)	125 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven)
Channel Processing	11.2	11.2
Dolby Atmos		up to 7.1.4 with external amp
DTS:X		up to 7.1.4 with external amp
DSD via HDMI	2-ch/Multi-ch Input	2-ch/Multi-ch Input
Auto Speaker Calibration System with Mic.	YPAO sound optimization with R.S.C., Multipoint, 3D, 64-Bit High Precision EQ Calculation and Angle measurement	Audyssey MultEQ XT32
HDR10
Dolby Vision
eARC	via firmware update
New HDCP Version	2.3	2.2
Analog To HDMI Upconversion	Component****, Composite	Component**, Composite
Wi-Fi	with Wireless Direct
Bluetooth	SBC, AAC	SBC
Works with Amazon Alexa	on MusicCast (Voice control using your Alexa device like Echo or Echo Dot)
Many HDMI Inputs	8 (1 front)	8 (1 front)
USB Input	USB memory, portable audio player	1 (Front) for USB memory
Many RCA Line Inputs	8 (1 front)	6 (1 front)
Phono Input
RCA Pre-Outs	11.2 (barter to Zone 2 and Zone 3)	11.2
Composite Video Inputs	4	4 (1 front)
Component Video Inputs	2	3
Ethernet
Zones	4	3
Analog Tuner	FM/AM	FM/AM with RDS
Spotify
Tidal

WEAKNESSES	Yamaha RX-A3070	Marantz SR7012
No Front Wide Channel Support
No Dolby Atmos Height Virtualization
No IMAX Enhanced
No HDR10+
No 8K Passthrough	up to 4K/60p 4:4:4	up to 4K 50/60Hz 4:4:4
Few 8K Inputs
No Digital Radio
Old Bluetooth Version	2․1 + EDR	3․0 + EDR

Yamaha RX-A3070	Marantz SR7012
9 channel Amplifier: Yamaha RX-A3070 features 9 channel power amplifier. It is rated at 150 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven) and is able to drive 4 ohm speakers.	9 channel Amplifier: Marantz SR7012 features 9 channel power amplifier. It is rated at 125 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven) and is able to drive 4 ohm speakers.

• Current Feedback Topology: Marantz SR7012 features Current Feedback Topology which is a well known, Marantz’ original circuit technology. The Current Feedback amplifier technology fits perfectly with the high requirements set for Super Audio software providing wide-bandwidth, high-speed reproduction. The impedance at the Current Feedback point is limited resulting in a very low phase shift. Marantz receivers and amplifiers equipped with Current Feedback can keep the phase compensation via Negative FeedBack (NFB) to a minimum, resulting in high through-rate, excellent transient response and superb sonic transparency for the full bandwidth. Unlike conventional Voltage Feedback amplification, the Current Feedback amplification makes the power amplifier in-sensitive to difficult loudspeaker loads.
• HDAM (Hyper Dynamic Amplifier Module): Marantz SR7012 features exclusive Marantz HDAM (Hyper Dynamic Amplifier Module) technology found on their Reference Series components. Marantz developed its own discrete circuit boards to replace standard IC's. These HDAM's consist of discrete surface mount components with short mirror image L/R signal paths. Those devices are doing exactly the same thing as the Op-Amps, but outperform the regular IC Op-amps dramatically in terms of the Slew Rate and reduced noise level, resulting in a much more dynamic, accurate and detailed sound. Over the years Marantz developed different types of the HDAM to improve quality and to fit to the special requirements of a product category like CD or amplifier.

AMPLIFIER	Yamaha RX-A3070	Marantz SR7012
Channels	9.2	9.2
Power Output	150 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven)	125 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven)
Front Wide Channel Support
THX™ Certification
Continuous 6 Ω Rated
Certified 4 Ω Performance
Bi-amp Capability		assignable

Yamaha RX-A3070's and Marantz SR7012's amplifiers can be assigned for different speaker configurations.

• Dolby Atmos Configurations: The following speaker configurations are supported for Dolby Atmos:
Yamaha RX-A3070: 5.2.2, 5.2.4, 7.2.2 with internal amplifier and 7.2.4 with addition of external 2 channel amplifier.
Marantz SR7012: 5.2.2, 5.2.4, 7.2.2 with internal amplifier and 7.2.4 with addition of external 2 channel amplifier.
• DTS:X Configurations: The following speaker configurations are supported for DTS:X:
Yamaha RX-A3070: The speaker configurations for DTS:X are the same as for Dolby Atmos - 5.2.2, 5.2.4, 7.2.2 with internal amplifier and 7.2.4 with addition of external 2 channel amplifier.
Marantz SR7012: The speaker configurations for DTS:X are the same as for Dolby Atmos - 5.2.2, 5.2.4, 7.2.2 with internal amplifier and 7.2.4 with addition of external 2 channel amplifier.
• Configurations without height channels: There are also other speaker configurations available which do not include height channels:
Yamaha RX-A3070: 5.2, 7.2 with internal amplifier.
Marantz SR7012: 5.2, 7.2 with internal amplifier.
• 2-ch Bi-Amp: Both models are able to bi-amp up to 2 main channels simultaneously. During bi-amplification two amplifiers are used for one speaker. One amplifier powers the midrange and tweeter section of the speaker and another amplifier powers the low frequency woofers. Each amplifier is less loaded and performs better. In order to use this feature speakers must have 2 pairs of connectors.

Dolby Atmos

Yamaha RX-A3070 and Marantz SR7012 support Dolby Atmos.

• Dolby Surround Upmixer: Both models support Dolby Surround Upmixer. If the content is not mixed in Dolby Atmos then the Dolby surround upmixer will expand the audio to all channels including ceiling speakers. The upmixer has replaced the Dolby Pro Logic II family with improved upmixing algorithms.

DTS:X

Yamaha RX-A3070 and Marantz SR7012 support DTS:X.

• DTS Neural:X: Both models feature DTS Neural:X which is an advanced upmixer that can take non DTS:X content and upmix it to the DTS:X speaker layout. It has replaced the DTS Neo family with improved flexibility.
• DTS Virtual:X: Yamaha RX-A3070 supports DTS Virtual:X which bridges the gap between DTS:X codec and the reality of so many consumers' homes, allowing you to enjoy multi-dimensional sound regardless of room size, layout, or speaker configuration. If you have a limited speaker setup you will miss a full immersive potential of your entertainment system. DTS Virtual:X adds height and surround audio effect to your system without adding height speakers. It works with multiple configurations and delivers immersive sound experience out of 5.1 or even 2.1 speaker layouts.
• DTS Dialog Control: Both models have DTS Dialog Control. This function adjusts the dialog levels during playback of the DTS:X stream. It allows you to separately increase the dialog levels in contrast with the background sound and hear dialog easily even under noisy circumstances.

Auro-3D

Marantz SR7012 supports Auro-3D.

• Auro-Matic upmixer: Auro-Matic upmixer takes non Auro-3D sound and upmixes to the current speaker configuration.

AUDIO DECODING	Yamaha RX-A3070	Marantz SR7012
Dolby Atmos		up to 7.1.4 with external amp
Dolby Atmos Height Virtualization
Dolby Atmos Music
Dolby TrueHD
Dolby Digital Plus
Dolby Surround Upmixer
Dolby Pro Logic
Dolby Digital EX
DTS:X		up to 7.1.4 with external amp
DTS Neural:X
DTS Virtual:X
DTS Neo	Neo:6
DTS-HD Master Audio
DTS-HD High Resolution Audio
DTS 96/24
DTS Express
DTS-ES	Discrete 6.1, Matrix 6.1	Discrete 6.1, Matrix 6.1
IMAX Enhanced
Auro 3D with Auro-Matic Upmixer		Built-In

Yamaha RX-A3070 comes with 8 HDMI inputs. It has 2 outputs - 1 for MAIN and 1 for Sub/Zone2/ZONE4.

Marantz SR7012 comes with 8 HDMI inputs. It has 3 outputs - 2 for MAIN and 1 for ZONE2.

• 4K/60Hz Passthrough: On both receivers all inputs pass up to 4K/60p 4:4:4 video signal.
• 4K Upscaling: Both receivers can upscale up to 4K 60p 4:4:4 from HDMI and analog sources.
• Analog To HDMI Upconversion: Both receivers support analog to HDMI Upconversion, so you can input your analog video sources and output them digitally via HDMI. This means that you will need only one HDMI cable to connect to your TV.
• BT.2020 Color Space: BT.2020 or Rec. 2020 is a color standard which delivers a wider color gamut compared to Rec. 709. It covers approximately 75% of the total visual spectrum while the Rec. 709 covers only 35% (available on both models).
• HDCP Copy Protection: Yamaha RX-A3070 is HDCP 2.3 and Marantz SR7012 is HDCP 2.2 compliant which is a requirement for 4K/HDR copy-protected content transmission.
• 3D Ready: Both receivers are able to pass 3D video through HDMI.

HDR (High Dynamic Range)

Both receivers support HDR10, Dolby Vision and Hybrid Log-Gamma. High dynamic range video has greater dynamic range than standard dynamic range (SDR) video with brighter whites and deeper blacks. The result is greater contrast and more details in dark and bright areas, better color and depth.

Enhanced Audio Return Channel (eARC)

Yamaha RX-A3070 and Marantz SR7012 support Audio Return Channel (ARC) which allows the compatible TV to send audio signal to the a/v receiver through the same HDMI cable which is used to send audio and video signals to the TV. So one HDMI cable is used to transfer audio signal in both directions. New Enhanced ARC will support uncompressed audio formats such as Dolby Atmos, DTS:X, Dolby TrueHD and DTS HD Master Audio whereas the previous ARC could support only Dolby Digital, Dolby Digital Plus, DTS, DTS HD, and PCM.

VIDEO FEATURES	Yamaha RX-A3070	Marantz SR7012
HDR10
HDR10+
Dynamic HDR
BT.2020 color space
Dolby Vision
HLG (Hybrid Log Gamma)
HDBaseT Compatible
Enhanced Audio Return Channel (eARC)	via firmware update
HDCP Version	2.3	2.2
QMS (Quick Media Switching)
ALLM (Auto Low Latency Mode)
VRR (Variable Refresh Rate)
QFT (Quick Frame transport)
3-D Ready
Video Signal Passthrough	up to 4K/60p 4:4:4	up to 4K 50/60Hz 4:4:4
Video Signal Upscaling	up to 4K 60p 4:4:4	up to 4K 50/60Hz 4:4:4

TERMINALS	Yamaha RX-A3070	Marantz SR7012
HDMI Inputs	8 (1 front)	8 (1 front)
HDMI Outputs	2 (1 for MAIN, 1 for Sub/Zone2/ZONE4)	3 (2 for MAIN, 1 for ZONE2)
8K Inputs
USB Input	USB memory, portable audio player	1 (Front) for USB memory
USB DC Out Port
Optical Inputs	3	2
Optical Outputs
Coaxial Inputs	3	2
RCA Line Inputs	8 (1 front)	6 (1 front)
RCA Line Outputs
XLR Line Inputs	1
Phono Input
Multi-Channel Input		7.1
RCA Pre-Outs	11.2 (barter to Zone 2 and Zone 3)	11.2
XLR Pre-outs
Composite Video Inputs	4	4 (1 front)
Composite Video Outputs		1
S-Video Inputs
S-Video Outputs
Component Video Inputs	2	3
Component Video Outputs		1

GENERAL	Yamaha RX-A3070	Marantz SR7012
Brand	Yamaha	Marantz
Series	Aventage
Model	RX-A3070	SR7012
Type	A/V Receiver	A/V Receiver
Country	USA and Canada	UK
Release Year	2017	2017
Predecessor	Yamaha RX-A3060	Marantz SR7011
Successor	Yamaha RX-A3080	Marantz SR7013

AMPLIFIER	Yamaha RX-A3070	Marantz SR7012
Channels	9.2	9.2
Power Output	150 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven)	125 W (8 Ω, 20 Hz - 20 kHz, 2 channel driven)
Front Wide Channel Support
Current Feedback Topology
Discrete Amplification
HDAM
THX™ Certification
Continuous 6 Ω Rated
Certified 4 Ω Performance
Bi-amp Capability		assignable

AUDIO FEATURES	Yamaha RX-A3070	Marantz SR7012
Surround:AI™
DAC	ESS SABRE PRO Premier DAC™ES9026PRO (for main 7 channels)	AKM AK4458
DAC Specs	192 kHz/32 Bit	768 kHz/32 Bit
Maximum Channel Processing	11.2	11.2
Air Studios Monitor Certification
Dolby Atmos		up to 7.1.4 with external amp
Dolby Atmos Height Virtualization
Dolby Atmos Music
Dolby TrueHD
Dolby Digital Plus
Dolby Surround Upmixer
Dolby Pro Logic
Dolby Digital EX
Surround EX
DTS:X		up to 7.1.4 with external amp
DTS Neural:X
DTS Virtual:X
DTS Neo	Neo:6
DTS-HD Master Audio
DTS-HD High Resolution Audio
DTS 96/24
DTS Express
DTS-ES	Discrete 6.1, Matrix 6.1	Discrete 6.1, Matrix 6.1
IMAX Enhanced
Auro 3D with Auro-Matic Upmixer		Built-In
PCM	2-ch/Multi-ch Input	2-ch/Multi-ch Input
Network Audio Formats	MP3, WMA, MPEG-4 AAC, Apple Lossless, WAV, FLAC, AIFF, DSD	MP3, WMA, MPEG-4 AAC, Apple Lossless, WAV, FLAC, DSD
Music Playback via USB	MP3, WMA, AAC, Apple Lossless, WAV, FLAC, AIFF, DSD	MP3, WMA, AAC, Apple Lossless, WAV, FLAC, DSD
High Resolution Music Playback via USB and/or Network	up to 192 kHz	up to 192 kHz
High Resolution Audio Formats via USB	Apple Lossless, WAV, FLAC, AIFF, DSD	Apple Lossless, WAV, FLAC, DSD
Gapless Playback
DSD via HDMI	2-ch/Multi-ch Input	2-ch/Multi-ch Input
DSD via USB	2-ch Input	2-ch Input
DSD to PCM Converter
USB DAC
Jitter Reduction
DTS Dialogue Control
Dialog Enhancement
Dialog Level Adjustment
Dialog normalization
Dialogue Lift	no presence speakers required
Compressed Music Enhancer	including enhancer for Bluetooth®	MDAX2
High-resolution Music Enhancer	up to 96/24
Adaptive DRC (Dynamic Range Control)
Initial Volume & Maximum Volume Setting
Audyssey Dynamic EQ
Audyssey Dynamic Volume
Audyssey LFC
Audyssey Sub EQ HT
Audyssey DSX
Direct Mode
Straight Decoding Mode
Pure Direct Mode	with Video On mode
CINEMA DSP	HD3
DSP Programs	24
SILENT CINEMA / Virtual CINEMA DSP	Virtual CINEMA FRONT
Virtual Speakers	including surround back
Independent Subwoofer Outputs

CALIBRATION	Yamaha RX-A3070	Marantz SR7012
Auto Speaker Calibration System with Mic.	YPAO sound optimization with R.S.C., Multipoint, 3D, 64-Bit High Precision EQ Calculation and Angle measurement	Audyssey MultEQ XT32
Audyssey App Support
YPAO Volume
PEQ for SUB	Down to 15.6 Hz
Optimized Bass Redirection
Bass Sync

VIDEO FEATURES	Yamaha RX-A3070	Marantz SR7012
HDR10
HDR10+
Dynamic HDR
BT.2020 color space
Dolby Vision
HLG (Hybrid Log Gamma)
HDBaseT Compatible
Enhanced Audio Return Channel (eARC)	via firmware update
HDCP Version	2.3	2.2
QMS (Quick Media Switching)
ALLM (Auto Low Latency Mode)
VRR (Variable Refresh Rate)
QFT (Quick Frame transport)
3-D Ready
Video Signal Passthrough	up to 4K/60p 4:4:4	up to 4K 50/60Hz 4:4:4
Video Signal Upscaling	up to 4K 60p 4:4:4	up to 4K 50/60Hz 4:4:4
Analog To HDMI Upconversion	Component****, Composite	Component**, Composite
Component Video Upscaling
Analog to Analog Video conversion
Component Video Maximum Resolution	1080i
Video Parameter Adjustments
isf Certified Calibration Control

CONNECTIVITY	Yamaha RX-A3070	Marantz SR7012
Wi-Fi	with Wireless Direct
Bluetooth	SBC, AAC	SBC
Works with Amazon Alexa	on MusicCast (Voice control using your Alexa device like Echo or Echo Dot)
Chromecast Built-In
Works with SonoS
HEOS
DTS Play-Fi
MHL Input
DLNA 1.5
MusicCast
Domotz Pro Compatible
Remote Monitoring with ihiji
OvrC Compatible
AirPlay	AirPlay	AirPlay 2
Apple Product Connection	iPod, iPhone and iPad	iPod, iPhone and iPad
Remote App	(iPhone® / iPad® / Android™ phone / tablet)	Marantz 2016 AVR Remote App for iOS and Android devices
InstaPrevue Input Source Prevue

TERMINALS	Yamaha RX-A3070	Marantz SR7012
HDMI Inputs	8 (1 front)	8 (1 front)
HDMI Outputs	2 (1 for MAIN, 1 for Sub/Zone2/ZONE4)	3 (2 for MAIN, 1 for ZONE2)
8K Inputs
USB Input	USB memory, portable audio player	1 (Front) for USB memory
USB DC Out Port
Optical Inputs	3	2
Optical Outputs
Coaxial Inputs	3	2
RCA Line Inputs	8 (1 front)	6 (1 front)
RCA Line Outputs
XLR Line Inputs	1
Phono Input
Multi-Channel Input		7.1
RCA Pre-Outs	11.2 (barter to Zone 2 and Zone 3)	11.2
XLR Pre-outs
Composite Video Inputs	4	4 (1 front)
Composite Video Outputs		1
S-Video Inputs
S-Video Outputs
Component Video Inputs	2	3
Component Video Outputs		1
Ethernet
Ethernet Switch
PC In
Front A/V Inputs	HDMI, USB, Analog Audio	HDMI, USB, Composite, L/R Audio
Speaker A/B		assignable
Headphone Out	6.3 mm (1/4")	6.3 mm (1/4")
Detachable Power Cord
Flasher In
Remote Control In/Out		1 / 1
dockport

ZONES	Yamaha RX-A3070	Marantz SR7012
Number of Zones	4	3
Powered Zones	Zone 2 / 3	2 and 3
Zone 2 Outs	HDMI, RCA Preout	HDMI, Component, Composite, Pre Out
Zone 3 Outs	RCA Preout	Pre Out
Zone 4 Outs	HDMI
Zone B Video Output	HDMI
Zone GUI
RS-232C Interface
+12V Trigger Output	2	2
Remote (IR) Input/Output	1 / 1
Party Mode

MISCELLANEOUS	Yamaha RX-A3070	Marantz SR7012
On-Screen Display	Graphical User Interface	Advanced Graphic User Interface
GUI Languages		9
SCENE	SCENE PLUS (12 sets)
Web Control
IP Control
PreAmp Mode
Display		2 lines + port hole
Remote Controller	(Preset)	RC035SR
Pre-programmed / Learnable / LCD Display		/ /
Setup Assistant

RADIO	Yamaha RX-A3070	Marantz SR7012
Analog Tuner	FM/AM	FM/AM with RDS
Presets	40
Digital Radio
Internet Radio		TuneIn
Pandora
Spotify
Tidal
Deezer
Napster
SiriusXM

CONSTRUCTION	Yamaha RX-A3070	Marantz SR7012
Front Panel		Metal
A.R.T. Wedge
Speaker Terminals	11	11
Large Speaker Terminals	11	11
Color-Coded Speaker Terminals
Transparent High-Grade Speaker Terminals
High Grade Audio Components
Gold plated RCA terminals

POWER	Yamaha RX-A3070	Marantz SR7012
Power Supply	AC 120 V, 60 Hz	AC 230 V, 50/60 Hz
Toroidal Transformer		(EI)
Power Consumption	490 W	710 W
No Sound Power		ECO On/Off: 65 W/110 W
Standby Power	0.1 W	0.2 W
ECO Mode / Hybrid Standby Function
Auto Power Standby
Auto Power off

PHYSICAL	Yamaha RX-A3070	Marantz SR7012
Dimensions (W x H x D)	435 mm x 192 mm x 474 mm (with antenna: 435 mm x 247 mm x 474 mm)	440 mm x 185 mm x 411 mm (with antenna: 440 mm x 247 mm x 411 mm) 17-3/8" x 7-3/8" x 16-1/4" (with antenna: 17-3/8" x 9-3/4" x 16-1/4"
Weight	18.1 kg (39.9 lbs)	14.2 kg (31 lbs 5 oz)

SPECIFICATIONS	Yamaha RX-A3070	Marantz SR7012
Power Output (8 Ω, 20 Hz - 20 kHz, 2 channel driven, FTC)	150 W (0.06% THD)	125 W (0.05% THD)
Power Output (8 Ω, 1 kHz, 2 channel Driven, FTC)	165 W (0.9% THD)
Rated Power Output (8 Ω, 1 kHz, 1 channel Driven)	185 W (0.9% THD)
Maximum Effective Output Power (8 Ω, 1 kHz, 1 channel Driven, JEITA)	230 W (10% THD)
Power Output (6 Ω, 20 Hz - 20 kHz, 2 channel driven)	165 W (0.06% THD)
Power Output (6 Ω, 1 kHz, 2 channel driven, FTC)		165 W (0.7% THD)
Power Output (6 Ω, 1 kHz, 1 channel driven, FTC)	200 W (0.9% THD)
Maximum Effective Power Output (6 Ω, 1 kHz, 1 channel driven, JEITA or IEC)	230 W (10% THD)	235 W (10% THD)
Rated Power Output (6 Ω, 1 kHz, 1 channel driven, IEC)		200 W (1% THD)
Dynamic Power per Channel (2 Ω, Front)	410 W
Dynamic Power per Channel (4 Ω, Front)	295 W
Dynamic Power per Channel (6 Ω, Front)	220 W
Dynamic Power per Channel (8 Ω, Front)	175 W
THD	0.04% (AUDIO 2 etc. to Speaker Out, 20 Hz - 20 kHz, 75 W, 8 Ω)
THD (Phono)	0.04% (Phono to PRE OUT, 1 kHz, 1 V)
THD (Digital)		0.008% (1 kHz, at 0 dB)
Analog Distortion		0.005% (20 Hz-20 kHz, Direct mode)
Phono Distortion		0.03% (1 kHz, 3 V)
Damping Factor	150 (Front, 1 kHz, 8 Ω)
Input Sensitivity and Impedance (Line)	200 mV/47 kΩ	200 mV/47 kΩ
Input Sensitivity and Impedance (Phono MM)	3.5 mV/47 kΩ	2.5 mV
Maximum Input Sensitivity (Line)	2.4 V (1 kHz, 0.5% THD)
Maximum Input Sensitivity (Phono)	45 mV (1 kHz, 0.5% THD)
Rated Preout Level and Impedance	1.0 V/1.2 kΩ
Rated Output digital		2 V (at 0 dB playback)
Maximum Preout Level and Impedance	2.0 V
S/N Ratio (Line, IHF-A)	110 dB	100 dB
S/N Ratio (Phono MM, IHF-A)	95 dB	74 dB
S/N Ratio (digital)		102 dB
Dynamic Range (digital)		100 dB
Phono RIAA Deviation	±0.5 dB (20 Hz - 20 kHz)	±1 dB (20 Hz to 20 kHz)
Frequency Response (Analog In)	+0/-3 dB (AUDIO etc., 10 Hz to 100 kHz)	+1/-3 dB (10 Hz to 100 kHz, Direct mode)
Residual noise (IHF-A Network)	150 µV (Speaker Out)
Channel Separation at 1 kHz/10 kHz (LINE)	75 dB/60 dB
Channel Separation at 1 kHz/10 kHz (Phono)	75 dB/60 dB
DSD Sampling Rates via HDMI	2.8 MHz	2.8 MHz
DSD Sampling Rates via USB	5.6 MHz, 2.8 MHz	5.6 MHz, 2.8 MHz
Video Input Sensitivity/Output Level and Impedance	1 Vp-p/75 Ω (Component Y) 0.7 Vp-p/75 Ω (Component PB/CB, PR/CR) 1 Vp-p/75 Ω (Composite)	1 Vp-p/75 Ω (Component Y) 0.7 Vp-p/75 Ω (Component PB/CB, PR/CR) 1 Vp-p/75 Ω (Composite)
Video Maximum Input	1.5 Vp-p
Video Frequency Response		5 Hz - 60 MHz, 0, -3 dB (Component) 5 Hz - 10 MHz, 0, -3 dB (Composite)
Ethernet Standard	10BASE-T/100BASE-TX	100BASE-TX
Wi-Fi Standard	IEEE 802.11 b/g/n	IEEE 802.11 a/b/g/n
Wi-Fi Terminal Frequency	2.4 GHz	5 GHz, 2.4 GHz
Bluetooth Version	2․1 + EDR	3․0 + EDR
Bluetooth Frequency	2.4 GHz	2.4 GHz
USB Terminal	USB2.0 5 V, 1 A	USB2.0 5V, 1 A
FM Frequency	87.5 MHz - 107.9 MHz	87.5 MHz - 108.0 MHz
FM 50 dB Quiet Sensitivity (IHF, 1 kHz, 100% MOD.)	Mono: 3 µV (20.8 dBf)
FM S/N Ratio	Mono/Stereo: 69 dB/68 dB
FM Harmonic Distortion (IHF, 1 kHz)	Mono/Stereo: 0.5%/0.6%
AM Frequency	530 kHz - 1710 kHz	522 kHz - 1611 kHz
AM Effective Sensitivity		18 µV
Warranty	3 Years	3 Years

* - 480i/576i and 480p/576p only
** - 480i/576i only
*** - no 1080p/24 upconversion
**** - 1080p signal is not converted
